HD6000 Series Shark Glam™ Hot Tool Air Styling & Drying System - Understanding your Glam Features

To change to hair dryer mode, slide down the hinge latch button on the back of the hair dryer and rotate the nozzle left until it clicks. (The nozzle is unlocked when the hinge latch button is held in the down position.)
To change back to styling wand mode, slide the hinge latch button down and rotate the nozzle back up until it clicks into place.

To engage Cool Shot, you must press the button and hold it down. The Cool Shot ends when the button is released. When the Cool Shot button is held down, you should feel the air turn from warm to room temperature in a few seconds, and the UI LED will turn dark blue. When you release the button, the temperature will return to the prior setting.

This is the Cool Shot button. When you hold it down, it turns off the heater and blows room-temperature air. This helps close the cuticle and smooth the hair at the end of styling.

Use the Cool Shot button to finish the style. When diffusing curls or when using the curlers, press and hold the Cool Shot button for 10 seconds to help lock in your style and set the shape of your curls or waves. To tame frizz using the Concentrator or Brush accessories, press and hold the Cool Shot button while moving downward from roots to ends. To shape ends using the Glossi Styler, wrap around the bristles and hold the Cool Shot button for 10 seconds."

To activate Scalp Shield, press the heat button for 2 seconds until the LED flashes BLUE.

LED will turn BLUE when switched to this mode. Use with Auto-Wrap Curlers, Silki Straightener, Glossi Styler

The LED will pulse ORANGE while it's heating up. Wait for LED to turn GREEN & airflow to turn on.

For wet mode, the temperatures are the following:
HIGH - 120°C (248°F)
MED - 110°C (230°F)
LOW - 100°C (212°F)

For dry mode, the temperatures are the following:
HIGH - 220°C (428°F)
MED - 200°C (392°F)
LOW - 180°C (356°F)
